GW-TB

Guy Wire Tie Back Kit

Find a Partner
Specifications
Finish making your selections or clear them to view relevant specifications.

Product Classification

Product Type Ice canopies and shields

General Specifications

Mounting Angle 60°, 203.2 mm (8 in) | Angle 90°, 152.4 mm (6 in) | Straight or tapered legs up to 203.2 mm (8 in) OD

Dimensions

Height 254 mm | 10 in
Width 1676.4 mm | 66 in
Length 1219.2 mm | 48 in

Material Specifications

Material Type Hot dip galvanized steel

Packaging and Weights

Included Brackets | Hardware | Saddle mount
Packaging quantity 1
Weight, net 57.1 kg | 125.884 lb

Product Classification

Product Type Ice canopies and shields

General Specifications

Mounting Angle 60°, 203.2 mm (8 in) | Angle 90°, 152.4 mm (6 in) | Straight or tapered legs up to 203.2 mm (8 in) OD

Dimensions

Height 254 mm | 10 in
Width 1676.4 mm | 66 in
Length 1219.2 mm | 48 in

Material Specifications

Material Type Hot dip galvanized steel

Packaging and Weights

Included Brackets | Hardware | Saddle mount
Packaging quantity 1
Weight, net 57.1 kg | 125.884 lb
