3X-V65S-C3-3XR 3X-V65S-C3-3XR
6-port small cell antenna, 6x 1695–2690 MHz, 65° HPBW, 3x RET.
3X-V65S-C3-3XR
  • Product Type: Small cell antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz
  • Horizontal Beamwidth: 65°
  • Length Size: 0.7 m (2 ft)
  • Width/Diameter: ≤ 200 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 6
  • RF Connector Quantity, high band: 6
3X-V65S-C3-3XR
  • Product Type: Small cell antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz
  • Horizontal Beamwidth: 65°
  • Length Size: 0.7 m (2 ft)
  • Width/Diameter: ≤ 200 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 6
  • RF Connector Quantity, high band: 6
DB992HG28N-B DB992HG28N-B
1-port small cell antenna, 1710–2490 MHz, 30° HPBW, fixed electrical tilt
DB992HG28N-B
  • Product Type: Small cell antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz
  • Horizontal Beamwidth: 33°
  • Length Size: 0.7 m (2 ft)
  • Width/Diameter: 306 – 353 mm
  • RF Connector Interface: N Female
  • RF Connector Quantity, total: 1
  • RF Connector Quantity, high band: 1
DB992HG28N-B
  • Product Type: Small cell antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz
  • Horizontal Beamwidth: 33°
  • Length Size: 0.7 m (2 ft)
  • Width/Diameter: 306 – 353 mm
  • RF Connector Interface: N Female
  • RF Connector Quantity, total: 1
  • RF Connector Quantity, high band: 1
NNV4SSP-360S-F2 NNV4SSP-360S-F2
18-port small cell antenna, 4x 698-896, 8x 1695–2690, 4x 3300- 4200 and 2x 5150-5925 MHz, 360° Horizontal Beamwidth, fixed tilt.
NNV4SSP-360S-F2
  • Product Type: Omnidirectional antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 3100 – 5000 MHz | 5000 – 6000 MHz | 575 – 960 MHz
  • Horizontal Beamwidth: 360°
  • Length Size: 0.7 m (2 ft)
  • Width/Diameter: 354 – 457 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 18
  • RF Connector Quantity, high band: 6
  • RF Connector Quantity, mid band: 8
  • RF Connector Quantity, low band: 4
NNV4SSP-360S-F2
  • Product Type: Omnidirectional antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 3100 – 5000 MHz | 5000 – 6000 MHz | 575 – 960 MHz
  • Horizontal Beamwidth: 360°
  • Length Size: 0.7 m (2 ft)
  • Width/Diameter: 354 – 457 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 18
  • RF Connector Quantity, high band: 6
  • RF Connector Quantity, mid band: 8
  • RF Connector Quantity, low band: 4
NNV4SSP-360S-F4 NNV4SSP-360S-F4
18-port small cell antenna, 4x 698-896, 8x 1695–2690, 4x 3400-3800 and 2x 5150-5925 MHz, 360° Horizontal Beamwidth, fixed tilt.
NNV4SSP-360S-F4
  • Product Type: Small cell antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 3100 – 5000 MHz | 5000 – 6000 MHz | 575 – 960 MHz
  • Horizontal Beamwidth: 360°
  • Length Size: 0.7 m (2 ft)
  • Width/Diameter: 354 – 457 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 18
  • RF Connector Quantity, high band: 14
  • RF Connector Quantity, low band: 4
NNV4SSP-360S-F4
  • Product Type: Small cell antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 3100 – 5000 MHz | 5000 – 6000 MHz | 575 – 960 MHz
  • Horizontal Beamwidth: 360°
  • Length Size: 0.7 m (2 ft)
  • Width/Diameter: 354 – 457 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 18
  • RF Connector Quantity, high band: 14
  • RF Connector Quantity, low band: 4
NNV4SSP-360S-F4-V4 NNV4SSP-360S-F4-V4
18-port small cell antenna, 4x 698-896, 8x 1695–2690, 4x 3300- 4200 and 2x 5150-5925 MHz, 360° Horizontal Beamwidth, fixed tilt.
NNV4SSP-360S-F4-V4
  • Product Type: Small cell antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 3100 – 5000 MHz | 575 – 960 MHz
  • Horizontal Beamwidth: 360°
  • Length Size: 0.7 m (2 ft)
  • Width/Diameter: 354 – 457 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 18
  • RF Connector Quantity, high band: 14
  • RF Connector Quantity, low band: 4
NNV4SSP-360S-F4-V4
  • Product Type: Small cell antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 3100 – 5000 MHz | 575 – 960 MHz
  • Horizontal Beamwidth: 360°
  • Length Size: 0.7 m (2 ft)
  • Width/Diameter: 354 – 457 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 18
  • RF Connector Quantity, high band: 14
  • RF Connector Quantity, low band: 4
NNVVSSP-360S-FM NNVVSSP-360S-FM
14-port quasi-omni antenna, 4x 698–896, 4x 1695–2690, 4x 3400-3800 and 2x 5150-5925 MHz, 360° horizontal beamwidth. Fixed and manual tilt.
NNVVSSP-360S-FM
  • Product Type: Small cell antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 3100 – 5000 MHz | 5000 – 6000 MHz | 575 – 960 MHz
  • Horizontal Beamwidth: 360°
  • Length Size: 0.7 m (2 ft)
  • Width/Diameter: 201 – 305 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 14
  • RF Connector Quantity, high band: 10
  • RF Connector Quantity, low band: 4
NNVVSSP-360S-FM
  • Product Type: Small cell antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 3100 – 5000 MHz | 5000 – 6000 MHz | 575 – 960 MHz
  • Horizontal Beamwidth: 360°
  • Length Size: 0.7 m (2 ft)
  • Width/Diameter: 201 – 305 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 14
  • RF Connector Quantity, high band: 10
  • RF Connector Quantity, low band: 4
QD-2402 QD-2402
1-port small cell antenna, 2400–2500 MHz, 27° HPBW, fixed electrical tilt
QD-2402
  • Product Type: Small cell antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz
  • Horizontal Beamwidth: 33°
  • Length Size: 0.7 m (2 ft)
  • Width/Diameter: 201 – 305 mm
  • RF Connector Interface: N Female
  • RF Connector Quantity, total: 1
  • RF Connector Quantity, high band: 1
QD-2402
  • Product Type: Small cell antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz
  • Horizontal Beamwidth: 33°
  • Length Size: 0.7 m (2 ft)
  • Width/Diameter: 201 – 305 mm
  • RF Connector Interface: N Female
  • RF Connector Quantity, total: 1
  • RF Connector Quantity, high band: 1
SS-65T-F SS-65T-F
4-port small cell antenna, 4x 3300–4200 MHz, 65° HPBW, fixed electrical tilt
SS-65T-F
  • Product Type: Small cell antenna
  • Operating Frequency Band Range: 3100 – 5000 MHz
  • Horizontal Beamwidth: 65°
  • Length Size: <0.7 m (2 ft)
  • Width/Diameter: ≤ 200 mm
  • RF Connector Interface: NEX10 Female
  • RF Connector Quantity, total: 4
  • RF Connector Quantity, high band: 4
SS-65T-F
  • Product Type: Small cell antenna
  • Operating Frequency Band Range: 3100 – 5000 MHz
  • Horizontal Beamwidth: 65°
  • Length Size: <0.7 m (2 ft)
  • Width/Diameter: ≤ 200 mm
  • RF Connector Interface: NEX10 Female
  • RF Connector Quantity, total: 4
  • RF Connector Quantity, high band: 4
UU-360S-F UU-360S-F
4-port small cell antenna, 4x 3300-5000 MHz. 360° Horizontal Beamwidth, fixed tilt.
UU-360S-F
  • Product Type: Small cell antenna
  • Operating Frequency Band Range: 3100 – 5000 MHz
  • Horizontal Beamwidth: 360°
  • Length Size: 0.7 m (2 ft)
  • Width/Diameter: 201 – 305 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 4
  • RF Connector Quantity, high band: 4
UU-360S-F
  • Product Type: Small cell antenna
  • Operating Frequency Band Range: 3100 – 5000 MHz
  • Horizontal Beamwidth: 360°
  • Length Size: 0.7 m (2 ft)
  • Width/Diameter: 201 – 305 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 4
  • RF Connector Quantity, high band: 4
V360QS-C3-3XR V360QS-C3-3XR
2-port small cell antenna, 2x 1695–2690 MHz, 360° HPBW, 1x RET
V360QS-C3-3XR
  • Product Type: Small cell antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz
  • Horizontal Beamwidth: 360°
  • Length Size: 0.7 m (2 ft)
  • Width/Diameter: ≤ 200 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 2
  • RF Connector Quantity, high band: 2
V360QS-C3-3XR
  • Product Type: Small cell antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz
  • Horizontal Beamwidth: 360°
  • Length Size: 0.7 m (2 ft)
  • Width/Diameter: ≤ 200 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 2
  • RF Connector Quantity, high band: 2
V4S4-360S-F2 V4S4-360S-F2
16-port small cell antenna, 8x 1695-2690, 8x 3100-4200 MHz, 360° Horizontal Beamwidth, fixed tilt.
V4S4-360S-F2
  • Product Type: Small cell antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 3100 – 5000 MHz
  • Horizontal Beamwidth: 360°
  • Length Size: 0.7 m (2 ft)
  • Width/Diameter: 354 – 457 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 16
  • RF Connector Quantity, high band: 16
  • RF Connector Quantity, low band: 0
V4S4-360S-F2
  • Product Type: Small cell antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 3100 – 5000 MHz
  • Horizontal Beamwidth: 360°
  • Length Size: 0.7 m (2 ft)
  • Width/Diameter: 354 – 457 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 16
  • RF Connector Quantity, high band: 16
  • RF Connector Quantity, low band: 0
V4S4P-360S-F2 V4S4P-360S-F2
18-port small cell antenna, 8x 1695-2690, 8x 3100- 4200,2x 5150-5925 MHz, 360° Horizontal Beamwidth, fixed tilt.
V4S4P-360S-F2
  • Product Type: Small cell antenna
  • Horizontal Beamwidth: 360°
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 18
  • RF Connector Quantity, high band: 18
  • RF Connector Quantity, low band: 0
V4S4P-360S-F2
  • Product Type: Small cell antenna
  • Horizontal Beamwidth: 360°
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 18
  • RF Connector Quantity, high band: 18
  • RF Connector Quantity, low band: 0
