CK9479-000 | FIST-OSKG

FIST Gel Sealing Kit for oval splice closure port, sealing 1 looped cable with diameter between 5 and 18 mm

Find a Partner

Specifications

Finish making your selections or clear them to view relevant specifications.

Features and Benefits

Unique gel-based mechanical sealing option used on fiber splice closure ports for blown, standard, mini- and micro-cables
Allows usage of multiple cable drops in a single closure outlet port, thus significantly increasing existing cable capacity
Ideal for fiber cables with thin outer jackets that are difficult to seal with standard heat shrinkable sleeves

Specifications

Product Classification

Application	For use with FIST-GCO2 Fiber closures
Cable Capacity, maximum	1
Color	Black

Single Cable Diameter, maximum	18 mm \| 0.709 in
Single Cable Diameter, minimum	5 mm \| 0.197 in

Included	Cable termination brackets \| Dummy plugs \| Multi-out gel seal
Packaging quantity	1

Agency	Classification
ROHS	Compliant/Exempted
CHINA-ROHS	Above maximum concentration value
REACH-SVHC	Compliant as per SVHC revision on www.commscope.com/ProductCompliance
UK-ROHS	Compliant/Exempted

Application	For use with FIST-GCO2 Fiber closures
Cable Capacity, maximum	1
Color	Black

Single Cable Diameter, maximum	18 mm \| 0.709 in
Single Cable Diameter, minimum	5 mm \| 0.197 in

Included	Cable termination brackets \| Dummy plugs \| Multi-out gel seal
Packaging quantity	1

Agency	Classification
ROHS	Compliant/Exempted
CHINA-ROHS	Above maximum concentration value
REACH-SVHC	Compliant as per SVHC revision on www.commscope.com/ProductCompliance
UK-ROHS	Compliant/Exempted
